230/530-B-MB-C3-REC-L3 T0517 FAG

All dimensions

1. Inner (d) MM 530
2. Outer (D) MM 780
3. Width (B) MM 185
4. Inner (d) Inch 20.8661
5. Outer (D) Inch 30.7087
6. Width (B) Inch 7.2835

Suffix description

1. B Modified Internal Construction
2. MB Solid Brass Cage, Guidance On Inner Ring
3. C3 Internal Clearance Larger Than Normal
4. REC Reconditioned (Re-Greased And Re-Packed By Manufacturer, Reports Available)
5. L3
6. T0517

Technical details

1. Availability 1 pc
2. Brand FAG
3. Item number 230/530-B-MB-C3-REC-L3 T0517 FAG
4. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 314

Product Properties

1. Bore C - Cylindrical Bore
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type M - Brass Cage
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
