23156CAME4C3S11 NSK

All dimensions

1. Inner (d) MM 280
2. Outer (D) MM 460
3. Width (B) MM 146
4. Inner (d) Inch 11.0236
5. Outer (D) Inch 18.1102
6. Width (B) Inch 5.748

Suffix description

1. CAM One Piece Brass Cage, Guide Ring
2. E4 Lubrication Groove And Holes In Bearing Outer Ring
3. C3 Internal Clearance Larger Than Normal
4. S11 Inner And Outer Ring Heat Stabilized To 200°C

Technical details

1. Availability 0 pcs
2. Brand NSK
3. Item number 23156CAME4C3S11 NSK
4. Also known as 23156B.MB.C3
   23156-BEA-MB1-C3
   23156-BEA-XL-MB1-C3
   23156-B-MB-C3
   23156CAC/C3W33
   23156CAM E4 C3
   23156-E1A-MB1-C3
   23156MB.C3

5. Category Spherical Roller Bearing

Weight and Dimensions

1. Weight (kg) 99.5

Product Properties

1. Bore C - Cylindrical Bore
2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
3. Seal No Seal
4. Cage Type M - Brass Cage
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Heat Stabilization S1 - Temperatures up to 200 °C
8. Vibrating Screen Execution Non Vibrating Screen Execution
