239/530-K-MB FAG

€ 11.697,88 ex VAT
€ 14.154,44 incl. VAT
€ 14.154,44 incl. VAT
€ 11.697,88 ex VAT
Guaranteed same day shipment on orders placed before 17.00h (CEST)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

239/530-K-MB FAG

Spherical roller bearing

Stock
1 pc in stock and ready for shipment
Brand FAG
Article number 239/530-K-MB FAG
Inside diameter 530mm
Outside diameter 710mm
Width 136mm
Product description

The 239/530-K-MB FAG is a spherical roller bearing. This bearing type has a solid inner ring, which runs on two rows of symmetrical rollers in a solid outer ring. The outer ring has a concave, spherical raceway. This design compensates for any alignment errors and shaft deflections. Spherical roller bearings can withstand particularly high radial loads. Additionally, they can accommodate axial forces in both directions. These bearings are used in elevators, textile machines, food processing machines, cranes etc.

Read more Show less
Help with this product

Downloads and links

Similar to: 239/530-K-MB FAG

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 530
  2. Outer (D) MM 710
  3. Width (B) MM 136
  4. Inner (d) Inch 20.8661
  5. Outer (D) Inch 27.9528
  6. Width (B) Inch 5.3543
  7. Width (b) mm 136

Suffix description

  1. K Tapered Bore, Taper 1:12
  2. MB Solid Brass Cage, Guidance On Inner Ring

Technical details

  1. Availability 1 pc
  2. Brand FAG
  3. Item number 239/530-K-MB FAG
  4. Also known as 0190401990000
  5. EAN 4012801299398
  6. Category Spherical Roller Bearing

Weight and Dimensions

  1. Weight (kg) 152

Product Properties

  1. Bore K - 1:12 Tapered Bore (Standard for Most Types)
  2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
  3. Seal No Seal
  4. Cage Type M - Brass Cage
  5. Radial Internal Play Cn Normal Internal Play
  6. Precision Standard Precision
  7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
  8. Vibrating Screen Execution Non Vibrating Screen Execution

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 6900000
  2. Radial Dynamic Load Rating Cr (N) 2850000
  3. Basic static load rating, radial (C 0r) "6900000.0000"
  4. Limiting speed (n G) 930
  5. Reference speed (n ϑr) 500
  6. ECLASS number 23-05-09-11
  7. ECLASS2 number 23-05-09-11
  8. Medias description Spherical roller bearing 239..-K-MB, symmetric 3 ribs
