23984-MB-C3 FAG

€ 6.975,10 ex VAT
€ 8.439,87 in VAT
€ 8.439,87 in VAT
€ 6.975,10 ex VAT
Guaranteed same day shipment on orders placed before 17.00h (CET)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

23984-MB-C3 FAG

Spherical roller bearing

Stock
1 pc in stock and ready for shipment
Brand FAG
Article number 23984-MB-C3 FAG
Inside diameter 420mm
Outside diameter 560mm
Width 106mm
Product description

The 23984-MB-C3 FAG is a spherical roller bearing. This bearing type has a solid inner ring, which runs on two rows of symmetrical rollers in a solid outer ring. The outer ring has a concave, spherical raceway. This design compensates for any alignment errors and shaft deflections. Spherical roller bearings can withstand particularly high radial loads. Additionally, they can accommodate axial forces in both directions. These bearings are used in elevators, textile machines, food processing machines, cranes etc.

Read more Show less
Help with this product

Downloads and links

Similar to: 23984-MB-C3 FAG

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 420
  2. Outer (D) MM 560
  3. Width (B) MM 106
  4. Inner (d) Inch 16.5354
  5. Outer (D) Inch 22.0472
  6. Width (B) Inch 4.1732
  7. Width (b) mm 106

Suffix description

  1. MB Solid Brass Cage, Guidance On Inner Ring
  2. C3 Internal Clearance Larger Than Normal

Technical details

  1. Availability 1 pc
  2. Brand FAG
  3. Item number 23984-MB-C3 FAG
  4. Also known as 0383811680030
  5. EAN 4012801194051
  6. Category Spherical Roller Bearing

Weight and Dimensions

  1. Weight (kg) 71.6

Product Properties

  1. Bore C - Cylindrical Bore
  2. Lubrication Enhancement W33 - Lubrication Groove and 3 Holes
  3. Seal No Seal
  4. Cage Type M - Brass Cage
  5. Radial Internal Play C3 Internal Play (Higher than Cn)
  6. Precision Standard Precision
  7. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
  8. Vibrating Screen Execution Non Vibrating Screen Execution

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 4450000
  2. Radial Dynamic Load Rating Cr (N) 1910000
  3. Basic static load rating, radial (C 0r) "4450000.0000"
  4. Limiting speed (n G) 1230
  5. Reference speed (n ϑr) 660
  6. ECLASS number 23-05-09-11
  7. ECLASS2 number 23-05-09-11
  8. Medias description Spherical roller bearing 239..-MB, symmetric 3 ribs

Downloads and links

  1. Link to manufacturer Link to manufacturer
Show all details Show less
