29344-E1-XL FAG

Spherical roller thrust bearing

Stock
3 pcs in stock and ready for shipment
Brand FAG
Article number 29344-E1-XL FAG
Inside diameter 220mm
Outside diameter 360mm
Width 85mm
Product description

The 29344-E1-XL FAG is a spherical roller thrust bearing. This type of bearing can handle high radial loads and extremely high axial loads in one direction simultaneously. The specially designed raceways of this bearing accommodate a large number of asymmetrical rolling elements. These rollers transfer the load from one raceway to another. This occurs at an angle relative to the bearing axis, while a flange on the shaft ring guides the rollers. Spherical roller thrust bearings, also known as axial spherical roller bearings, have the highest load-carrying capacity of all thrust bearings. Additionally, they can achieve relatively high rotational speeds.

The 29344-E1-XL FAG allows for a compact bearing arrangement. Additionally, this bearing can accommodate misalignments. Spherical roller thrust bearings are self-aligning, allowing them to handle slight misalignments between the shaft ring and the housing ring. Shaft deflections, alignment errors, and housing deformations can be compensated to some extent by the bearing. Spherical roller thrust bearings are often mounted in conjunction with spherical roller bearings to increase the axial load capacity of the bearing arrangement. Common applications include turbines, generators, and hydraulic presses.

Read more Show less
Help with this product

Downloads and links

Similar to: 29344-E1-XL FAG

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 220
  2. Outer (D) MM 360
  3. Width (B) MM 85
  4. Inner (d) Inch 8.6614
  5. Outer (D) Inch 14.1732
  6. Width (B) Inch 3.3465
  7. Height (T) mm 85

Suffix description

  1. E1 Increased Capacity Design
  2. XL X-Life

Technical details

  1. Availability 3 pcs
  2. Brand FAG
  3. Item number 29344-E1-XL FAG
  4. Also known as 0389999510000
    29344-E1
  5. EAN 4012802190069
  6. Category Spherical Roller Thrust Bearing

Weight and Dimensions

  1. Weight (kg) 33.2

Product Properties

  1. Cage Type S - Steel or Standard Cage

Data from Schaeffler (medias)

  1. Axial Static Load Rating C0a (N) 6200000
  2. Axial Dynamic Load Rating Ca (N) 1990000
  3. Limiting speed (n G) 1820
  4. Reference speed (n ϑr) 950
  5. ECLASS number 23-05-11-03
  6. ECLASS2 number 23-05-11-03
  7. Medias description Axial spherical roller bearing 293..-E1-XL, no flanging ring

Downloads and links

  1. X-life brochure X-life brochure
  2. Link to manufacturer Link to manufacturer
