31313-XL-DF-A80-120 FAG

All dimensions

1. Inner (d) MM 65
2. Outer (D) MM 140
3. Width (B) MM 72
4. Inner (d) Inch 2.5591
5. Outer (D) Inch 5.5118
6. Width (B) Inch 2.8346
7. Inner ring total width (2B) mm 66
8. Outer ring total width (2T) mm 72

Suffix description

1. XL X-Life
2. DF Two Tapered Roller Bearings Matched In An X Arrangement,With An Intermediate Ring Between The Outer Rings
3. A80-120 Axial Clearance In µm

Technical details

1. Availability 3 pcs
2. Brand FAG
3. Item number 31313-XL-DF-A80-120 FAG
4. Also known as 0880632084080
   31313-DF-A80-120

5. EAN 4054369707120
6. Category Tapered Roller Bearing Single Row (paired metric)

Weight and Dimensions

1. Weight (kg) 5.1

Product Properties

1. Tapered Roller Pair Internal Play 80-120µm

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 375000
2. Radial Dynamic Load Rating Cr (N) 330000
3. Basic static load rating, radial (C 0r) "375000.0000"
4. Limiting speed (n G) 5500
5. Thermal speed rating (n ϑr) 3650
6. ECLASS number 23-05-09-10
7. ECLASS2 number 23-05-09-10
8. Medias description Tapered roller bearing set 313..-XL-DF, X-arrangement
