32BD4718T12DDUKCG26 ENSL NSK

All dimensions

1. Inner (d) MM 32
2. Outer (D) MM 47
3. Width (B) MM 18
4. Inner (d) Inch 1.2598
5. Outer (D) Inch 1.8504
6. Width (B) Inch 0.7087

Suffix description

1. T12 Glass Fibre Reinforced Cage
2. DDU Rubber Seals At Each Side Of The Bearing
3. K Tapered Bore, Taper 1:12
4. CG26 Radial Clearance In Microns
5. ENS Lubricant, Temperature Range -40 ~ 160°C, Peak +180°C
6. L Amount Of Grease Is Approximately. 20% To 30%

Technical details

1. Availability 2 pcs
2. Brand NSK
3. Item number 32BD4718T12DDUKCG26 ENSL NSK
4. Category Deep Groove Ball Bearing Double Row

Weight and Dimensions

1. Weight (kg) 0.083

Product Properties

1. Bore K - 1:12 Tapered Bore (Standard for Most Types)
2. Seal 2RS - Rubber Seal on Two Sides
3. Cage Type TB - Hard Fiber Cage
4. External Modification No External Modification
5. Radial Internal Play Special Internal Clearance
6. Precision Standard Precision
7. Lubrication Higher and Lower Temperature Grease
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
