3312-B-2RSR-TVH-C3 FAG

€ 280,92 ex VAT
€ 339,92 incl. VAT
€ 339,92 incl. VAT
€ 280,92 ex VAT
Guaranteed same day shipment on orders placed before 17.00h (CET)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

3312-B-2RSR-TVH-C3 FAG

Double row angular contact ball bearing

Stock
10 pcs in stock and ready for shipment
Brand FAG
Article number 3312-B-2RSR-TVH-C3 FAG
Inside diameter 60mm
Outside diameter 130mm
Width 54mm
Product description

The 3312-B-2RSR-TVH-C3 FAG is a double row angular contact ball bearing with solid inner- and outer rings. The design of this bearing type resembles two single row angular contact ball bearings in O-arrangement but is slightly narrower. Also, the contact angle and the design of the bearing rings are different. double row angular contact ball bearings can support high radial forces and axial forces in both directions. The greater the contact angle, the greater the axial load capacity of the bearing.

Read more Show less
Help with this product

Similar to: 3312-B-2RSR-TVH-C3 FAG

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 60
  2. Outer (D) MM 130
  3. Width (B) MM 54
  4. Inner (d) Inch 2.3622
  5. Outer (D) Inch 5.1181
  6. Width (B) Inch 2.126

Suffix description

  1. B Internal Design Modification
  2. 2RSR Seal At Each Side Of The Bearing
  3. TVH Moulded Polyamide Cage Snap-Type, Rolling Element Riding
  4. C3 Internal Clearance Larger Than Normal

Technical details

  1. Availability 10 pcs
  2. Brand FAG
  3. Item number 3312-B-2RSR-TVH-C3 FAG
  4. Also known as 0392540620030
  5. EAN 4064328013001
  6. Category Angular Contact Ball Bearing Double Row

Weight and Dimensions

  1. Weight (kg) 2.9298

Product Properties

  1. Bore C - Cylindrical Bore
  2. Seal 2RS - Rubber Seal on Two Sides
  3. Cage Type P - Plastic Molded Cage
  4. External Modification No External Modification
  5. Radial Internal Play C3 Internal Play (Higher than Cn)
  6. Precision Standard Precision
  7. Lubrication Standard Lubrication
  8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
  9. Split Inner ring / Outer ring Standard
