4208BTNH RHP

All dimensions

1. Inner (d) MM 40
2. Outer (D) MM 80
3. Width (B) MM 23
4. Inner (d) Inch 1.5748
5. Outer (D) Inch 3.1496
6. Width (B) Inch 0.9055

Suffix description

1. B Internal Design Modification
2. TNH Polyamide Snap-On Cage, Located On The Rolling Elements

Technical details

1. Availability 4 pcs
2. Brand RHP
3. Item number 4208BTNH RHP
4. EAN 00747023054152
5. Category Deep Groove Ball Bearing Double Row

Weight and Dimensions

1. Weight (kg) 0.545

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type P - Plastic Molded Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
