6000-C-2BRS FAG

All dimensions

1. Inner (d) MM 10
2. Outer (D) MM 26
3. Width (B) MM 8
4. Inner (d) Inch 0.3937
5. Outer (D) Inch 1.0236
6. Width (B) Inch 0.315
7. Width (b) mm 8

Suffix description

1. C Deep Groove Ball Bearings Of Generation C, Modified Internal Construction
2. 2BRS Non Contact Labyrinth Seals On Both Sides

Technical details

1. Availability 65 pcs
2. Brand FAG
3. Item number 6000-C-2BRS FAG
4. Also known as 0620097100000
   0960455580000
   6000-2BRS

5. EAN 4047643120029
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.018

Product Properties

1. Bore C - Cylindrical Bore
2. Seal 2RU - Two Seals / Non Contact Type
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 1970
2. Radial Dynamic Load Rating Cr (N) 5000
3. Basic static load rating, radial (C 0r) "1970.0000"
4. Limiting speed (n G) 38000
5. Reference speed (n ϑr) 30000
6. ECLASS number 23-05-08-01
7. ECLASS2 number 23-05-08-01
8. Medias description Deep groove ball bearings 60..-C-2BRS, Main dimensions to DIN 625-1, labyrinth seal on both sides
