6004.2Z.T9H.P63.GLY32 Zwicker

All dimensions

1. Inner (d) MM 20
2. Outer (D) MM 42
3. Width (B) MM 12
4. Inner (d) Inch 0.7874
5. Outer (D) Inch 1.6535
6. Width (B) Inch 0.4724

Suffix description

1. 2Z Two Metallic Shields
2. T9H Snap Cage, Glass-Fibre-Reinforced Polyamide, Ball Riding
3. P63 Combination Of P6 (Dimensional And Running Accuracy To ISO Tolerance Class 6 (Better Than Normal)) And C3 (Internal Clearance Larger Than Normal)
4. GLY32 Lubricant Identifier, E.G. Klüber Asonic GLY32- Thickener: Lithium - Base Oil: Ester+ Synthetic Hydrocarbon - Operational Temperature Range: -50°C ~ +140°C

Technical details

1. Availability 0 pcs
2. Brand Zwicker
3. Item number 6004.2Z.T9H.P63.GLY32 Zwicker
4. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.066

Product Properties

1. Bore C - Cylindrical Bore
2. Seal ZZ/2Z - Steel Seal on Two Sides
3. Cage Type P - Plastic Molded Cage
4. External Modification No External Modification
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision P6 Precision (Higher than Standard)
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment
