6007-2RSR-C3 FAG

Rubber seal (2 sides) Higher (internal) clearance 35x62x14mm

Stock
433 pcs in stock and ready for shipment
Brand FAG
Article number 6007-2RSR-C3 FAG
Inside diameter 35mm
Outside diameter 62mm
Width 14mm
Product description
The 6007-2RSR-C3 FAG is a deep groove ball bearing with a single row design. Deep groove ball bearings have a straight forward design, are robust in operation and are easy to maintain. Deep groove ball bearings reduce rotational friction and support both radial and axial loads.

The 6007-2RSR-C3 FAG is suitable for high speeds and can operate with low noise.

The dimensions of the 6007-2RSR-C3 FAG are: Bore (or inner diameter) 35mm, Outer diameter 62mm and Width (or thickness) 14mm.

6000 serie
The 6007-2RSR-C3 FAG is part of the popular 6000 serie which contain extra light ball bearings and are perfect for limited space applications.The 6000 serie is used in a wide range of industrial processes as well as DIY applications like: skateboards, inline skates, bicycles, washing and drying machines.

Seal
The 2RSR suffix indicates that the bearing has a rubber seal on both sides. If necessary the seals can easily removed if the application requires only 1 seal. The rubber seal protects the ingress of moisture, dust or other dirt. The bearings are filled with a high quality grease and are lubricated for life.

Internal play
The C3 in the product name means that this bearing has a higher (internal) clearance than normal. The C3 clearance is most frequently used for this type of bearings. The extra internal clearance allows expansion due to high speeds or temperatures.

About FAG
FAG is a brand of the Schaeffler Group Industrial originated in Germany. The Schaeffler Group produces two major bearing brands: FAG and INA. FAG is known for its strength in innovation, high-quality standards and wide portfolio of bearings and related products. If you choose to buy a product from FAG you are ensured of a top quality product.
Read more Show less
Help with this product

Downloads and links

Similar to: 6007-2RSR-C3 FAG

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 35
  2. Outer (D) MM 62
  3. Width (B) MM 14
  4. Inner (d) Inch 1.378
  5. Outer (D) Inch 2.4409
  6. Width (B) Inch 0.5512
  7. Width (b) mm 14

Suffix description

  1. 2RSR Rubber Seals At Each Side Of The Bearing
  2. C3 Internal Clearance Larger Than Normal

Technical details

  1. Availability 433 pcs
  2. Brand FAG
  3. Item number 6007-2RSR-C3 FAG
  4. Also known as 0167174490030
  5. EAN 4012801063036
  6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

  1. Weight (kg) 0.159

Product Properties

  1. Bore C - Cylindrical Bore
  2. Seal 2RS - Rubber Seal on Two Sides
  3. Cage Type S - Steel or Standard Cage
  4. External Modification No External Modification
  5. Radial Internal Play C3 Internal Play (Higher than Cn)
  6. Precision Standard Precision
  7. Lubrication Standard Lubrication
  8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
  9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 10300
  2. Radial Dynamic Load Rating Cr (N) 17000
  3. Basic static load rating, radial (C 0r) "10300.0000"
  4. Limiting speed (n G) 6200
  5. ECLASS number 23-05-08-01
  6. ECLASS2 number 23-05-08-01
  7. Medias description Deep groove ball bearing 60..-2RSR, single row, cf. DIN 625-1
