6305-TVH-C3 FAG

All dimensions

1. Inner (d) MM 25
2. Outer (D) MM 62
3. Width (B) MM 17
4. Inner (d) Inch 0.9843
5. Outer (D) Inch 2.4409
6. Width (B) Inch 0.6693
7. Width (b) mm 17

Suffix description

1. TVH Solid Cage Made From Glass Fibre Reinforced Polyamide 66
2. C3 Internal Clearance Larger Than Normal

Technical details

1. Availability 23 pcs
2. Brand FAG
3. Item number 6305-TVH-C3 FAG
4. Also known as 0384523910030

5. EAN 4012801064903
6. Category Deep Groove Ball Bearings Single Row

Weight and Dimensions

1. Weight (kg) 0.225

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type P - Plastic Molded Cage
4. External Modification No External Modification
5. Radial Internal Play C3 Internal Play (Higher than Cn)
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 11500
2. Limiting speed (n G) 16200
3. Reference speed (n ϑr) 12300
