BAH-0031D SKF

All dimensions

1. Inner (d) MM 35
2. Outer (D) MM 68
3. Width (B) MM 37
4. Inner (d) Inch 1.378
5. Outer (D) Inch 2.6772
6. Width (B) Inch 1.4567

Suffix description

1. D Double Row Angular Contact Ball Bearing With A Two-Piece Inner Ring

Technical details

1. Availability 0 pcs
2. Brand SKF
3. Item number BAH-0031D SKF
4. Also known as 430042C
   DAC35680037

5. Category Deep Groove Ball Bearing Double Row

Weight and Dimensions

1. Weight (kg) 0.52

Product Properties

1. Bore C - Cylindrical Bore
2. Seal No Seal
3. Cage Type S - Steel or Standard Cage
4. External Modification No External Modification
5. Radial Internal Play Cn Normal Internal Play
6. Precision Standard Precision
7. Lubrication Standard Lubrication
8. Heat Stabilization No Heat Stabilization - Temperatures up to 120 °C
9. Special Treatment I - Lubr Holes on Locating Side
