BSB2562-SU FAG

All dimensions

1. Inner (d) MM 25
2. Outer (D) MM 62
3. Width (B) MM 15
4. Inner (d) Inch 0.9843
5. Outer (D) Inch 2.4409
6. Width (B) Inch 0.5906
7. Width (b) mm 15

Suffix description

1. SU Universal Bearing; Single Bearings Can Be Used In Sets In Any Combination Required

Technical details

1. Availability 0 pcs
2. Brand FAG
3. Item number BSB2562-SU FAG
4. Also known as 0396208080000

5. EAN 4054369012903
6. Category Angular Contact Thrust Ball Bearings, Single Direction

Weight and Dimensions

1. Weight (kg) 0.24

Product Properties

1. Cage Type P - Plastic Molded Cage
2. Precision Standard Precision

Data from Schaeffler (medias)

1. Basic dynamic load rating, axial (C a) 29000
2. Basic static load rating, axial (C 0a) 64000
3. Limiting speed for grease lubrication (n G Grease) 6700
4. Thermally safe operating speed (n ϑ) 5400
