EGB1220-E50-Y INA

Bushing

Stock
1,026 pcs in stock and ready for shipment
Brand INA
Article number EGB1220-E50-Y INA
Inside diameter 12mm
Outside diameter 14mm
Width 20mm
Product description

The EGB1220-E50-Y INA is a bushing. Bushings have a very simple, one-piece cylindrical design without rolling elements. Instead, they have a sliding contact where the shaft slides into the bore. This construction makes these bushings a cost-effective and reliable solution. Additionally, they are easy to install and require little installation space. The direct contact between the bushing and the shaft results in greater friction between the surfaces. Compared to roller bearings, they have lower speed and load capacities. Bushings are primarily used for rotating, oscillating, and linear movements.

Read more Show less
Help with this product

Downloads and links

Similar to: EGB1220-E50-Y INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 12
  2. Outer (D) MM 14
  3. Width (B) MM 20
  4. Inner (d) Inch 0.4724
  5. Outer (D) Inch 0.5512
  6. Width (B) Inch 0.7874
  7. Outer diameter (D o) mm 14
  8. Width (b) mm 20

Suffix description

  1. E50 Steel Backing With Sintered Layer Of Tin Bronze. Pore Filling And Covering Layer (0,3 And 0,4mm, Resp.) Of PTFE With Friction-Reducing Additives
  2. Y Schaeffler Factory Code

Technical details

  1. Availability 1,026 pcs
  2. Brand INA
  3. Item number EGB1220-E50-Y INA
  4. Also known as 0702297160000
    PAP1220-P20
  5. EAN 4012802760101
  6. Category Bushing

Weight and Dimensions

  1. Weight (kg) 0.0046

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 33600
  2. Radial Dynamic Load Rating Cr (N) 16800
  3. Basic static load rating, radial (C 0r) "33600.0000"
  4. ECLASS number 23-05-01-91
  5. ECLASS2 number 23-05-01-91
  6. Medias description Metal/polymer composite plain bush, low-maintenance, ISO 3547, with steel backing
