EGB2020-E50-Y INA

€ 1,54 ex VAT
€ 1,86 incl. VAT
€ 1,86 incl. VAT
€ 1,54 ex VAT
Guaranteed same day shipment on orders placed before 17.00h (CET)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

EGB2020-E50-Y INA

Bushing

Stock
802 pcs in stock and ready for shipment
Brand INA
Article number EGB2020-E50-Y INA
Inside diameter 20mm
Outside diameter 23mm
Width 20mm
Product description

The EGB2020-E50-Y INA is a bushing. Bushings have a very simple, one-piece cylindrical design without rolling elements. Instead, they have a sliding contact where the shaft slides into the bore. This construction makes these bushings a cost-effective and reliable solution. Additionally, they are easy to install and require little installation space. The direct contact between the bushing and the shaft results in greater friction between the surfaces. Compared to roller bearings, they have lower speed and load capacities. Bushings are primarily used for rotating, oscillating, and linear movements.

Read more Show less
Help with this product

Downloads and links

Similar to: EGB2020-E50-Y INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 20
  2. Outer (D) MM 23
  3. Width (B) MM 20
  4. Inner (d) Inch 0.7874
  5. Outer (D) Inch 0.9055
  6. Width (B) Inch 0.7874
  7. Outer diameter (D o) mm 23
  8. Width (b) mm 20

Suffix description

  1. E50 Steel Backing With Sintered Layer Of Tin Bronze. Pore Filling And Covering Layer (0,3 And 0,4mm, Resp.) Of PTFE With Friction-Reducing Additives
  2. Y Schaeffler Factory Code

Technical details

  1. Availability 802 pcs
  2. Brand INA
  3. Item number EGB2020-E50-Y INA
  4. Also known as 0702423560000
    GLY.PG202320A
    PAP2020-P20
  5. EAN 4012802760163
  6. Category Bushing

Weight and Dimensions

  1. Weight (kg) 0.013

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 56000
  2. Radial Dynamic Load Rating Cr (N) 28000
  3. Basic static load rating, radial (C 0r) "56000.0000"
  4. ECLASS number 23-05-01-91
  5. ECLASS2 number 23-05-01-91
  6. Medias description Metal/polymer composite plain bush, low-maintenance, ISO 3547, with steel backing

Downloads and links

  1. Link to manufacturer Link to manufacturer
Show all details Show less
