F512-WB-L FAG

Name: F512-WB-L FAG
Brand: FAG

€ 225,58 ex VAT

€ 272,95 incl. VAT

€ 225,58 ex VAT

	Guaranteed same day shipment on orders placed before 17.00h (CET)
	This product is available from stock
	Worldwide shipping from the Netherlands
	30 days return policy
	Track your order through Track & Trace

F512-WB-L FAG

Housing

Stock	178 pcs in stock and ready for shipment
Brand	FAG
Article number	F512-WB-L FAG
Outside diameter	206mm
Width	73mm

Product description

The F512-WB-L FAG housing is a robust industrial solution for bearings with higher load ratings. The bearing is available separately. These housings simplify the installation of bearings and shafts, while also offering support and protection to the bearings. They improve maintenance efficiency and extend the bearing's lifespan. Consequently, the F512-WB-L FAG housing provides enhanced convenience and reduced costs.

Email us at: help@247industries.com Response within 24h

Downloads and links

Link to manufacturer

Similar to: F512-WB-L FAG

Loading similair products

Product specifications

Outside diameter 206mm
Width 73mm

All dimensions

Outer (D) MM 206
Width (B) MM 73
Shaft diameter (d 1) mm 55
Flange width (a) mm 206
Height flange (h 1) mm 185
Total width with cover (g 2) mm 84

Suffix description

W Plummer Block Housings, Non-Split For Wide Bearings
B Open On Both Sides
L Flake Graphite Cast Iron (Standard)

Technical details

Availability 178 pcs
Brand FAG
Item number F512-WB-L FAG
Also known as 0383830200000
EAN 4012801213134
Category Housing / Y-Housing

Weight and Dimensions

Weight (kg) 4.8

Data from Schaeffler (medias)

Number of fastening holes 3
ECLASS number 23-05-17-02
ECLASS2 number 23-05-17-02
Medias description Flanged housing for various bearing types, wide version with conical bore and clamping sleeve, continuous shaft
