F522-WB-L FAG

Housing

Stock
3 pcs in stock and ready for shipment
Brand FAG
Article number F522-WB-L FAG
Outside diameter 270mm
Width 128mm
Product description

The F522-WB-L FAG housing is a robust industrial solution for bearings with higher load ratings. The bearing is available separately. These housings simplify the installation of bearings and shafts, while also offering support and protection to the bearings. They improve maintenance efficiency and extend the bearing's lifespan. Consequently, the F522-WB-L FAG housing provides enhanced convenience and reduced costs.

Read more Show less
Help with this product

Downloads and links

Similar to: F522-WB-L FAG

Loading similair products

Product specifications

All dimensions

  1. Outer (D) MM 270
  2. Width (B) MM 128
  3. Shaft diameter (d 1) mm 100
  4. Flange width (a) mm 270
  5. Height flange (h 1) mm 270
  6. Total width with cover (g 2) mm 137

Suffix description

  1. W Plummer Block Housings, Non-Split For Wide Bearings
  2. B Open On Both Sides
  3. L Flake Graphite Cast Iron (Standard)

Technical details

  1. Availability 3 pcs
  2. Brand FAG
  3. Item number F522-WB-L FAG
  4. Also known as 0383830800000
  5. EAN 4012801213219
  6. Category Housing / Y-Housing

Weight and Dimensions

  1. Weight (kg) 22.2

Data from Schaeffler (medias)

  1. Number of fastening holes 4
  2. ECLASS number 23-05-17-02
  3. ECLASS2 number 23-05-17-02
  4. Medias description Flanged housing for various bearing types, wide version with conical bore and clamping sleeve, continuous shaft
