GIHRK100-DO-C INA

Rod end

Stock
2 pcs in stock and ready for shipment
Brand INA
Article number GIHRK100-DO-C INA
Inside diameter 100mm
Outside diameter 230mm
Width 70mm
Product description

The GIHRK100-DO-C INA is a rod end. Rod ends consist of a housing with integral shank and a spherical plain bearing. This plain bearing is composed of an inner and outer ring without rolling elements. Rod ends are often mounted on the end of hydraulic or pneumatic cylinders. They are also used to connect two shafts. Rod ends can accommodate misalignment, and they support radial forces in a tensile or compressive direction.

The GIHRK100-DO-C INA has a spherical plain bearing with a steel-on-steel sliding contact. Both the outer and inner rings of this bearing are made of steel. Bearings with steel-on-steel sliding contacts are wear-resistant and have a high load carrying capacity. This bearing type requires regular maintenance. Proper lubrication is required to reduce friction and prevent fouling and corrosion.

Read more Show less
Help with this product

Downloads and links

Similar to: GIHRK100-DO-C INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 100
  2. Outer (D) MM 230
  3. Width (B) MM 70
  4. Inner (d) Inch 3.937
  5. Outer (D) Inch 9.0551
  6. Width (B) Inch 2.7559
  7. Outside diameter bearing (D) mm 150

Suffix description

  1. DO Sliding Contact Surface Steel/Steel
  2. C The Significance Of This Sign Is Not Determined Separately. They Are In Need For Appointment Of Special Features Of The Construction Of Internal Form External Uses. In General, The Use These Only Temporarily, During A Transitional Time To Avoid Confusion. In Some Cases, They Also For Permanent Appointment Of Bearings And Parts Of The Same Type And Size, But With A Differ Interior Design. (Source: Ina-Catalogue No. 307)'

Technical details

  1. Availability 2 pcs
  2. Brand INA
  3. Item number GIHRK100-DO-C INA
  4. Also known as 0978903910000
    SIR100ES
    TAPR100U
  5. EAN 4064327804426
  6. Category Rod End

Weight and Dimensions

  1. Weight (kg) 30

Product Properties

  1. Seal No Seal
  2. Contact Material Steel on Steel

Data from Schaeffler (medias)

  1. Radial Clearance (G r) CN
  2. Basic static load rating, radial (C 0r) 920000
