GIKL20-PW INA

Rod end

Stock
13 pcs in stock and ready for shipment
Brand INA
Article number GIKL20-PW INA
Inside diameter 20mm
Outside diameter 50mm
Width 25mm
Product description

The GIKL20-PW INA is a rod end. Rod ends consist of a housing with integral shank and a spherical plain bearing. This plain bearing is composed of an inner and outer ring without rolling elements. Rod ends are often mounted on the end of hydraulic or pneumatic cylinders. They are also used to connect two shafts. Rod ends can accommodate misalignment, and they support radial forces in a tensile or compressive direction.

The GIKL20-PW INA has a spherical plain bearing with a steel-on-PTFE sliding contact, making it maintenance-free. PTFE is a special plastic. During the run-in period of these plain bearings, particles of PTFE are deposited on the opposite running surface. They fill in the small irregularities of the inner ring surface, creating a smooth surface. As a result, the components fit each other perfectly.

Read more Show less
Help with this product

Downloads and links

Similar to: GIKL20-PW INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 20
  2. Outer (D) MM 50
  3. Width (B) MM 25
  4. Inner (d) Inch 0.7874
  5. Outer (D) Inch 1.9685
  6. Width (B) Inch 0.9843
  7. Outside diameter bearing (D) mm 40
  8. Width inner ring (B) mm 25

Suffix description

  1. PW Sliding Contact Surface Steel/PTFE (Polyetrafluoroethylene) Bronze Film

Technical details

  1. Availability 13 pcs
  2. Brand INA
  3. Item number GIKL20-PW INA
  4. Also known as 0066348850000
  5. EAN 4012802525892
  6. Category Rod End

Weight and Dimensions

  1. Weight (kg) 0.38

Product Properties

  1. Seal No Seal
  2. Contact Material Steel on PTFE

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 45600
  2. Radial Dynamic Load Rating Cr (N) 56600
  3. Basic static load rating, radial (C 0r) "45600.0000"
  4. ECLASS number 23-05-01-05
  5. ECLASS2 number 23-05-01-05
  6. Medias description Rod end with internal thread, left hand thread maintenance-free, sliding layer: PTFE film brass outer ring, DIN ISO 12240-4, dimension series K, type F, open design
