GK25-DO INA

Rod end

Stock
11 pcs in stock and ready for shipment
Brand INA
Article number GK25-DO INA
Inside diameter 25mm
Outside diameter 65mm
Width 20mm
Product description

The GK25-DO INA is a rod end. Rod ends consist of a housing with integral shank and a spherical plain bearing. This plain bearing is composed of an inner and outer ring without rolling elements. Rod ends are often mounted on the end of hydraulic or pneumatic cylinders. They are also used to connect two shafts. Rod ends can accommodate misalignment, and they support radial forces in a tensile or compressive direction.

The GK25-DO INA has a spherical plain bearing with a steel-on-steel sliding contact. Both the outer and inner rings of this bearing are made of steel. Bearings with steel-on-steel sliding contacts are wear-resistant and have a high load carrying capacity. This bearing type requires regular maintenance. Proper lubrication is required to reduce friction and prevent fouling and corrosion.

Read more Show less
Help with this product

Downloads and links

Similar to: GK25-DO INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 25
  2. Outer (D) MM 65
  3. Width (B) MM 20
  4. Inner (d) Inch 0.9843
  5. Outer (D) Inch 2.5591
  6. Width (B) Inch 0.7874
  7. Outside diameter bearing (D) mm 42
  8. Width inner ring (B) mm 20

Suffix description

  1. DO Steel/Steel & Inner And Outer Ring Hardened

Technical details

  1. Availability 11 pcs
  2. Brand INA
  3. Item number GK25-DO INA
  4. Also known as 0066357760000
    SC25ES
    TS25C
  5. EAN 4012802527209
  6. Category Rod End

Weight and Dimensions

  1. Weight (kg) 0.43

Product Properties

  1. Seal No Seal
  2. Contact Material Steel on Steel

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 70800
  2. Radial Dynamic Load Rating Cr (N) 48300
  3. Basic static load rating, radial (C 0r) "70800.0000"
  4. ECLASS number 23-05-01-05
  5. ECLASS2 number 23-05-01-05
  6. Medias description Hydraulic rod end, with circular welding face, requiring maintenance, sliding contact surface: steel/steel DIN ISO 12240-4 dimension series E, type S open design
