K89409-TV/0-8 INA

All dimensions

1. Inner (d) MM 45
2. Outer (D) MM 100
3. Width (B) MM 11
4. Inner (d) Inch 1.7717
5. Outer (D) Inch 3.937
6. Width (B) Inch 0.4331

Suffix description

1. TV Solid Cage Of Glass-Fibre Reinforced Polyamide, Ball Riding
2. /0-8 Micron - Needle Sort

Technical details

1. Availability 0 pcs
2. Brand INA
3. Item number K89409-TV/0-8 INA
4. Also known as 0001147409064

5. EAN 4054362427056
6. Category Cylindrical Roller Bearing with Cage (assembly)

Weight and Dimensions

1. Weight (kg) 0.268

Product Properties

1. Cage Type P - Plastic Molded Cage
2. Precision Standard Precision

Data from Schaeffler (medias)

1. ECLASS number 23-05-11-90
2. ECLASS2 number 23-05-11-90

Downloads and links

1. Link to manufacturer Link to manufacturer
