KGBAO30-PP-AS INA

Linear ball bearing and housing units (heavy range) KGBAO..PP AS, open design, s

Stock
18 pcs in stock and ready for shipment
Brand INA
Article number KGBAO30-PP-AS INA
Inside diameter 30mm
Outside diameter 84mm
Width 68mm
Product description

The KGBAO30-PP-AS INA is a linear ball bearing unit or ball bushing unit that is part of INA's machined range. The linear bearing is firmly anchored in its housing. The robust construction of the housing allows use of the full load capacity of the ball bushing.

The open design makes this type suitable for use on a supported shaft. In addition, this linear ball bearing unit is adjustable via a groove for custom radial clearances. Simple screw fastening makes mounting the bearing on the connection construction child's play, and a convenient centering edge on the housing facilitates alignment. Finally, centering holes allow for fast, additional dowel connection.

Read more Show less
Help with this product

Downloads and links

Similar to: KGBAO30-PP-AS INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 30
  2. Outer (D) MM 84
  3. Width (B) MM 68
  4. Inner (d) Inch 1.1811
  5. Outer (D) Inch 3.3071
  6. Width (B) Inch 2.6772
  7. Height (H) mm 63,5
  8. Length (L) mm 68

Suffix description

  1. PP Lip Seal On Both Sides Of Bearing
  2. AS Lubrication Holes In The Outer Ring Or Lubrication Groove In The Housing

Technical details

  1. Availability 18 pcs
  2. Brand INA
  3. Item number KGBAO30-PP-AS INA
  4. Also known as 0017438800000
  5. EAN 4012802047974
  6. Category Linear Ball Bearing Unit

Weight and Dimensions

  1. Weight (kg) 0.53

Product Properties

  1. Seal 2L - LS-seal at Both Sides

Data from Schaeffler (medias)

  1. Load capacity dyn. C (C) 3700
  2. ECLASS number 23-30-03-06
  3. ECLASS2 number 23-30-03-06
