KN50-B-PP INA

All dimensions

1. Inner (d) MM 50
2. Outer (D) MM 75
3. Width (B) MM 100
4. Inner (d) Inch 1.9685
5. Outer (D) Inch 2.9528
6. Width (B) Inch 3.937
7. Length (L) mm 100

Suffix description

1. B Guideways And Carriages May Only Be Combined With Each Other Within The Same Accuracy And Interchangeability Class, So A Can Only Be Combined With A, And B Can Only Be Combined With B
2. PP Lip Seal On Both Sides Of Bearing

Technical details

1. Availability 13 pcs
2. Brand INA
3. Item number KN50-B-PP INA
4. Also known as 0244642520000
   KN50100PP
   LBCD50A-2LS
   LMES50UU
   R0670-250-40
   SPM50WW
   TK50UU

5. EAN 4012802597677
6. Category Linear Ball Bearing

Weight and Dimensions

1. Weight (kg) 0.44

Product Properties

1. Seal 2L - LS-seal at Both Sides

Data from Schaeffler (medias)

1. Load capacity dyn. (C min) 9300
2. Load capacity stat. (C 0 min) 6500
3. Load capacity stat. (C 0 max) 8300
4. ECLASS number 23-30-03-01
5. ECLASS2 number 23-30-03-01
6. Medias description Linear ball bearings KN..-B-PP, Lightweight range, closed design, sealed on all sides, with relubrication facility, adjustable angle
