KS16 INA

All dimensions

1. Inner (d) MM 16
2. Outer (D) MM 26
3. Width (B) MM 36
4. Inner (d) Inch 0.6299
5. Outer (D) Inch 1.0236
6. Width (B) Inch 1.4173
7. Length (L) mm 36

Technical details

1. Availability 37 pcs
2. Brand INA
3. Item number KS16 INA
4. Also known as 0067137420000

5. EAN 4012802051131
6. Category Linear Ball Bearing

Weight and Dimensions

1. Weight (kg) 0.028

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Load capacity dyn. (C min) 1060
2. Load capacity stat. (C 0 min) 950
3. Load capacity stat. (C 0 max) 1550
4. ECLASS number 23-30-03-01
5. ECLASS2 number 23-30-03-01
6. Medias description Linear ball bearings KS.., heavy load range, gap seals on both sides

Downloads and links

1. Link to manufacturer Link to manufacturer
