KUVS10-B INA

All dimensions

1. Inner (d) MM 31,8
2. Outer (D) MM 51,6
3. Width (B) MM 11
4. Inner (d) Inch 1.252
5. Outer (D) Inch 2.0315
6. Width (B) Inch 0.4331
7. Width rail (b) mm 31,8
8. Width system (B) mm 51,6
9. Length linear recirculating ball bearing units (L) mm 47
10. Height rail (h) mm 10
11. Max. length rail (l max) mm 1960

Suffix description

1. B Standard Carriage, Four-Row, Full Complement Ball Set

Technical details

1. Availability 40 pcs
2. Brand INA
3. Item number KUVS10-B INA
4. Also known as 0054000580000
   KUVS32-B

5. EAN 4054362930624
6. Category Linear Ball Bearing Unit

Weight and Dimensions

1. Weight (kg) 0.025

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Load capacity dyn. C (C) 5700
2. Load capacity dyn C0 (C 0) 10600
3. ECLASS number 23-30-04-90
4. ECLASS2 number 23-30-04-90
