KWSE25-RROC-V1-G3 INA

All dimensions

1. Inner (d) MM 23
2. Outer (D) MM 70
3. Width (B) MM 81,8
4. Inner (d) Inch 0.9055
5. Outer (D) Inch 2.7559
6. Width (B) Inch 3.2205
7. Width carriage (B) mm 70
8. Overall length carriage (L) mm 81,8

Suffix description

1. RROC Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free
2. V1 Slight Preload
3. G3 Precision Class 3

Technical details

1. Availability 10 pcs
2. Brand INA
3. Item number KWSE25-RROC-V1-G3 INA
4. Also known as 0785633990240
   KWSE25-RROC-G3-V1

5. EAN 4054362947417
6. Category Linear Plain Bearing Unit

Weight and Dimensions

1. Weight (kg) 0.6

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Dynamic load rating, load direction I: compressive load (I C) 28000
2. Static load rating, load direction I: compressive load (I C 0) 67000
3. Dynamic load rating, load direction II: tensile load (II C) 26000
4. Static load rating, load direction II: tensile load (II C 0) 45000
5. Dynamic load rating; basic dynamic load rating, Load direction III: lateral load (III C) 28000
6. Static load rating, Load direction III: lateral load (III C 0) 47000
7. ECLASS number 23-30-04-90
8. ECLASS2 number 23-30-04-90
9. Medias description Standard carriage for six-row linear recirculating ball bearing and guideway assembly
