KWVE25-B-E-V2-G2 INA

All dimensions

1. Inner (d) MM 27,83
2. Outer (D) MM 73
3. Width (B) MM 83,3
4. Inner (d) Inch 1.0957
5. Outer (D) Inch 2.874
6. Width (B) Inch 3.2795
7. Width carriage (B) mm 73
8. Overall length carriage (L) mm 83,3

Suffix description

1. B Standard Carriage, Four-Row, Full Complement Ball Set
2. E Expanded Design (Carriage Without Screw Threads)
3. V2 Preload Class 2
4. G2 Precision Class 2

Technical details

1. Availability 2 pcs
2. Brand INA
3. Item number KWVE25-B-E-V2-G2 INA
4. Also known as 0570037500330
   KWVE25-B-E-G2-V2

5. EAN 4054362981367
6. Category Linear Plain Bearing Unit

Weight and Dimensions

1. Weight (kg) 0.725

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Dynamic load rating (C) 17900
2. Static load rating (C 0) 37000
3. Static moment rating about X axis (M 0x) 510
4. Static moment rating about Y axis (M 0y) 395
5. Static moment rating about Z axis (M 0z) 395
6. ECLASS number 23-30-04-90
7. ECLASS2 number 23-30-04-90
8. Medias description Carriages KWVE..-B-E, standard carriage, four-row, full complement, expanded type
