KWVE30-W-V0-G4 INA

All dimensions

1. Inner (d) MM 80
2. Outer (D) MM 142
3. Width (B) MM 97,6
4. Inner (d) Inch 3.1496
5. Outer (D) Inch 5.5906
6. Width (B) Inch 3.8425
7. Width carriage (B) mm 142
8. Overall length carriage (L) mm 97,5

Suffix description

1. W Wide Carriage
2. V0 Little To No Preload
3. G4 Precision Class 4

Technical details

1. Availability 10 pcs
2. Brand INA
3. Item number KWVE30-W-V0-G4 INA
4. Also known as 0213141100150
   KWVE30-W-G4-V0

5. EAN 4054366348883
6. Category Linear Plain Bearing Unit

Weight and Dimensions

1. Weight (kg) 1.95

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Dynamic load rating (C) 27500
2. Static load rating (C 0) 55000
3. Static moment rating about X axis (M 0x) 2660
4. Static moment rating about Y axis (M 0y) 700
5. Static moment rating about Z axis (M 0z) 700
6. ECLASS number 23-30-04-90
7. ECLASS2 number 23-30-04-90
8. Medias description Carriages KWVE..-W, wide carriage for linear recirculating ball bearing and guideway assembly
