KWVE35-B-EC-V2-G3 INA

All dimensions

1. Inner (d) MM 34
2. Outer (D) MM 100
3. Width (B) MM 76,2
4. Inner (d) Inch 1.3386
5. Outer (D) Inch 3.937
6. Width (B) Inch 3
7. Width carriage (B) mm 100
8. Overall length carriage (L) mm 76,2

Suffix description

1. B Version
2. EC Expanded Design, Short Carriage (Carriage Without Screw Threads)
3. V2 Preload Class 2
4. G3 Precision Class 3

Technical details

1. Availability 2 pcs
2. Brand INA
3. Item number KWVE35-B-EC-V2-G3 INA
4. Also known as 0200582760340
   KWVE35-B-EC-G3-V2

5. EAN 4054366341747
6. Category Linear Plain Bearing Unit

Weight and Dimensions

1. Weight (kg) 1.04

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Dynamic load rating (C) 24600
2. Static load rating (C 0) 39000
3. Static moment rating about X axis (M 0x) 790
4. Static moment rating about Y axis (M 0y) 330
5. Static moment rating about Z axis (M 0z) 330
6. ECLASS number 23-30-04-90
7. ECLASS2 number 23-30-04-90
8. Medias description Carriages KWVE..-B-EC, expanded interchangeability, short carriage, four-row
