KWVE35-B-N-RROC-V2-G3 INA

All dimensions

1. Inner (d) MM 34
2. Outer (D) MM 100
3. Width (B) MM 112
4. Inner (d) Inch 1.3386
5. Outer (D) Inch 3.937
6. Width (B) Inch 4.4094
7. Width carriage (B) mm 100
8. Overall length carriage (L) mm 112

Suffix description

1. B Version
2. N Low Carriage
3. RROC Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free
4. V2 Preload Class 2
5. G3 Precision Class 3

Technical details

1. Availability 2 pcs
2. Brand INA
3. Item number KWVE35-B-N-RROC-V2-G3 INA
4. Also known as 0782428600340
   KWVE35-B-N-RROC-G3-V2

5. EAN 4054366883247
6. Category Linear Plain Bearing Unit

Weight and Dimensions

1. Weight (kg) 1.56

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Dynamic load rating (C) 38000
2. Static load rating (C 0) 72000
3. Static moment rating about X axis (M 0x) 1465
4. Static moment rating about Y axis (M 0y) 1020
5. Static moment rating about Z axis (M 0z) 1020
6. ECLASS number 23-30-04-90
7. ECLASS2 number 23-30-04-90
8. Medias description Carriages KWVE..-B-N, low carriage, four-row

Downloads and links

1. Link to manufacturer Link to manufacturer
