KWVE55-B-SL-RROC-V2-G3 INA

All dimensions

1. Inner (d) MM 53
2. Outer (D) MM 100
3. Width (B) MM 211,6
4. Inner (d) Inch 2.0866
5. Outer (D) Inch 3.937
6. Width (B) Inch 8.3307
7. Width carriage (B) mm 100
8. Overall length carriage (L) mm 211,6

Suffix description

1. B Version
2. SL Narrow, Long Carriage
3. RROC Protected Against Corrosion By Corrotect® Special Coating - Cr(VI)-Free
4. V2 Preload Class 2
5. G3 Precision Class 3

Technical details

1. Availability 2 pcs
2. Brand INA
3. Item number KWVE55-B-SL-RROC-V2-G3 INA
4. Also known as 0782117600340

5. EAN 4054366882387
6. Category Linear Plain Bearing Unit

Weight and Dimensions

1. Weight (kg) 6.3

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Dynamic load rating (C) 127000
2. Static load rating (C 0) 285000
3. Static moment rating about X axis (M 0x) 7500
4. Static moment rating about Y axis (M 0y) 4725
5. Static moment rating about Z axis (M 0z) 4800
