LMB8UU IKO

All dimensions

1. Inner (d) MM 12,7
2. Outer (D) MM 22,23
3. Width (B) MM 31,75
4. Inner (d) Inch 0.5
5. Outer (D) Inch 0.875
6. Width (B) Inch 1.25

Suffix description

1. UU The Two Seal Types Incorporate Seals With Superior Dust Protection Performance At Both Ends Of The External Cylinder For Preventing Intrusion Of Foreign Matter. The Maximum Allowable Temperature For Seals Is 120°C

Technical details

1. Availability 1 pc
2. Brand IKO
3. Item number LMB8UU IKO
4. Also known as SW8GUU

5. Category Linear Ball Bearing

Weight and Dimensions

1. Weight (kg) 0.042

Product Properties

1. Seal 2RS - Rubber Seal on Two Sides
