LS150190 INA

All dimensions

1. Inner (d) MM 150
2. Outer (D) MM 190
3. Width (B) MM 9,5
4. Inner (d) Inch 5.9055
5. Outer (D) Inch 7.4803
6. Width (B) Inch 0.374
7. Outside diameter track washer (D) mm 190
8. Width (b) mm 9,5
9. Chamfer width (a min) mm 1,5

Technical details

1. Availability 3 pcs
2. Brand INA
3. Item number LS150190 INA
4. Also known as 0000552200000

5. EAN 4054363033911
6. Category Washer for Needle Roller Thrust Bearings

Weight and Dimensions

1. Weight (kg) 0.796

Data from Schaeffler (medias)

1. Chamfer angle 45
2. ECLASS number 23-05-91-90
3. ECLASS2 number 23-05-91-90
4. Medias description Bearing washers, suitable for AXK and K811
