NA4900-XL-C3 INA

All dimensions

1. Inner (d) MM 10
2. Outer (D) MM 22
3. Width (B) MM 13
4. Inner (d) Inch 0.3937
5. Outer (D) Inch 0.8661
6. Width (B) Inch 0.5118
7. Width (b) mm 13

Suffix description

1. XL X-Life
2. C3 Internal Clearance Larger Than Normal

Technical details

1. Availability 20 pcs
2. Brand INA
3. Item number NA4900-XL-C3 INA
4. Also known as 0506594210030
   NA4900-C3

5. EAN 4012802732481
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.023

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Basic static load rating, radial (C 0r) 9200
2. Limiting speed (n G) 24600
3. Limiting speed for grease lubrication (n G Grease) 14800
4. Reference speed (n ϑr) 16400
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07

Downloads and links

1. X-life brochure X-life brochure
2. Link to manufacturer Link to manufacturer
