NK40/30-XL INA

All dimensions

1. Inner (d) MM 40
2. Outer (D) MM 50
3. Width (B) MM 30
4. Inner (d) Inch 1.5748
5. Outer (D) Inch 1.9685
6. Width (B) Inch 1.1811
7. Under roller diameter (F w) mm 40

Suffix description

1. XL X-Life

Technical details

1. Availability 121 pcs
2. Brand INA
3. Item number NK40/30-XL INA
4. Also known as 0507542970000
   NB405030
   NK40/30
   RNA405030
   TAF405030

5. EAN 4012802267501
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.125

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 79000
2. Radial Dynamic Load Rating Cr (N) 44000
3. Basic static load rating, radial (C 0r) "79000.0000"
4. Limiting speed (n G) 11400
5. Reference speed (n ϑr) 6700
6. ECLASS number 23-05-09-07
7. ECLASS2 number 23-05-09-07
8. Medias description Needle roller bearings NK, light series
