NK8/12-TV-XL INA

All dimensions

1. Inner (d) MM 8
2. Outer (D) MM 15
3. Width (B) MM 12
4. Inner (d) Inch 0.315
5. Outer (D) Inch 0.5906
6. Width (B) Inch 0.4724
7. Under roller diameter (F w) mm 8

Suffix description

1. TV Polyamide Cage
2. XL X-Life

Technical details

1. Availability 478 pcs
2. Brand INA
3. Item number NK8/12-TV-XL INA
4. Also known as 0507532580000
   NK8/12TN
   NK8/12-TV

5. EAN 4012802733303
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.0091

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 4100
2. Radial Dynamic Load Rating Cr (N) 4450
3. Basic static load rating, radial (C 0r) "4100.0000"
4. Limiting speed (n G) 32500
5. Reference speed (n ϑr) 37000
6. ECLASS number 23-05-09-07
7. ECLASS2 number 23-05-09-07
8. Medias description Needle roller bearings NK, light series

Downloads and links

1. X-life brochure X-life brochure
2. Link to manufacturer Link to manufacturer
