NKIS25-XL INA

All dimensions

1. Inner (d) MM 25
2. Outer (D) MM 47
3. Width (B) MM 22
4. Inner (d) Inch 0.9843
5. Outer (D) Inch 1.8504
6. Width (B) Inch 0.8661
7. Width (b) mm 22

Suffix description

1. XL X-Life

Technical details

1. Availability 26 pcs
2. Brand INA
3. Item number NKIS25-XL INA
4. Also known as 0507709850000
   NKIS25

5. EAN 4054363051601
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.174

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 43500
2. Radial Dynamic Load Rating Cr (N) 38000
3. Basic static load rating, radial (C 0r) "43500.0000"
4. Limiting speed (n G) 13200
5. Limiting speed for grease lubrication (n G Grease) 7900
6. Reference speed (n ϑr) 7100
7. ECLASS number 23-05-09-07
8. ECLASS2 number 23-05-09-07
9. Medias description Needle roller bearings NKIS, heavy series
