PBY30-XL INA

Housing unit

Stock
23 pcs in stock and ready for shipment
Brand INA
Article number PBY30-XL INA
Inside diameter 30mm
Outside diameter 119mm
Width 38mm
Product description

The PBY30-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: PBY30-XL INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 30
  2. Outer (D) MM 119
  3. Width (B) MM 38
  4. Inner (d) Inch 1.1811
  5. Outer (D) Inch 4.685
  6. Width (B) Inch 1.4961
  7. Length total (L) mm 117,5
  8. Height (H 2) mm 66,1

Suffix description

  1. XL X-Life

Technical details

  1. Availability 23 pcs
  2. Brand INA
  3. Item number PBY30-XL INA
  4. Also known as 0008604330000
    PBY30
  5. EAN 4012802797701
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 0.4

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 11300
  2. Radial Dynamic Load Rating Cr (N) 20700
  3. Basic static load rating, radial (C 0r) "11300.0000"
  4. Load carrying capacity (housing) (C 0r G) 2700
  5. ECLASS number 23-05-16-01
  6. ECLASS2 number 23-05-16-01
  7. Medias description Plummer block housing unit PBY..-XL, RIBB sheet metal PB

Downloads and links

  1. X-life brochure X-life brochure
  2. Link to manufacturer Link to manufacturer
