PCFTR25-XL INA

Housing unit

Stock
29 pcs in stock and ready for shipment
Brand INA
Article number PCFTR25-XL INA
Inside diameter 25mm
Outside diameter 97mm
Width 36mm
Product description

The PCFTR25-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: PCFTR25-XL INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 25
  2. Outer (D) MM 97
  3. Width (B) MM 36
  4. Inner (d) Inch 0.9843
  5. Outer (D) Inch 3.8189
  6. Width (B) Inch 1.4173
  7. Total height unit (U) mm 36

Suffix description

  1. XL X-Life

Technical details

  1. Availability 29 pcs
  2. Brand INA
  3. Item number PCFTR25-XL INA
  4. Also known as 0008317940000
    PCFTR25
  5. EAN 4012802791037
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 0.71

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 7800
  2. Radial Dynamic Load Rating Cr (N) 14900
  3. Basic static load rating, radial (C 0r) "7800.0000"
  4. ECLASS number 23-05-16-02
  5. ECLASS2 number 23-05-16-02
  6. Medias description Housing units PCFTR, three-bolt flanged housing units, cast iron, eccentric locking collar, P seals

Downloads and links

  1. X-life brochure X-life brochure
  2. Link to manufacturer Link to manufacturer
