PCJ17-XL INA

€ 27,01 ex VAT
€ 32,68 incl. VAT
€ 32,68 incl. VAT
€ 27,01 ex VAT
Guaranteed same day shipment on orders placed before 17.00h (CET)
This product is available from stock
Worldwide shipping from the Netherlands
30 days return policy
Track your order through Track & Trace
iDeal, Mastercard, Visa, PayPal

PCJ17-XL INA

Housing unit

Stock
25 pcs in stock and ready for shipment
Brand INA
Article number PCJ17-XL INA
Inside diameter 17mm
Outside diameter 76mm
Width 39,1mm
Product description

The PCJ17-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: PCJ17-XL INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 17
  2. Outer (D) MM 76
  3. Width (B) MM 39,1
  4. Inner (d) Inch 0.6693
  5. Outer (D) Inch 2.9921
  6. Width (B) Inch 1.5394
  7. Flange width (L) mm 76
  8. Total height unit (U) mm 39,1

Suffix description

  1. XL X-Life

Technical details

  1. Availability 25 pcs
  2. Brand INA
  3. Item number PCJ17-XL INA
  4. Also known as 0009481010000
    16203 + F203
    16203 + FG203S
    F16203
    FG16203
    FY17FM
    GRAE17NPPB + CJ03
    PCJ17
    YET203 + FY503M
  5. EAN 4012802802665
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 0.415

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 4750
  2. Radial Dynamic Load Rating Cr (N) 10100
  3. Basic static load rating, radial (C 0r) "4750.0000"
  4. ECLASS number 23-05-16-02
  5. ECLASS2 number 23-05-16-02
  6. Medias description Housing units PCJ, four-bolt flanged housing units, cast iron, eccentric locking collar, P seals

Downloads and links

  1. X-life brochure X-life brochure
  2. Link to manufacturer Link to manufacturer
Show all details Show less
