PHEY40-XL INA

Name: PHEY40-XL INA
Brand: INA

€ 63,00 ex VAT

€ 76,23 incl. VAT

€ 63,00 ex VAT

	Guaranteed same day shipment on orders placed before 17.00h (CET)
	This product is available from stock
	Worldwide shipping from the Netherlands
	30 days return policy
	Track your order through Track & Trace

PHEY40-XL INA

Housing unit

Stock	59 pcs in stock and ready for shipment
Brand	INA
Article number	PHEY40-XL INA
Inside diameter	40mm
Outside diameter	135mm
Width	100mm

Product description

The PHEY40-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Start a chat
Call us at: +31 (0)85 00 22 247
Email us at: help@247industries.com Response within 24h

Downloads and links

Similar to: PHEY40-XL INA

Loading similair products

Product specifications

Inside diameter 40mm
Outside diameter 135mm
Width 100mm

All dimensions

Inner (d) MM 40
Outer (D) MM 135
Width (B) MM 100
Inner (d) Inch 1.5748
Outer (D) Inch 5.315
Width (B) Inch 3.937
Length total (L) mm 135
Housing total width (M) mm 100
Width housing (A 2) mm 36

Suffix description

XL X-Life

Technical details

Availability 59 pcs
Brand INA
Item number PHEY40-XL INA
Also known as 0009493020000
GAY40NPPB + HE08
PHEY40
EAN 4012802802122
Category Housing and Bearing (assembly)

Weight and Dimensions

Weight (kg) 1.54

Product Properties

Seal 2F - Standard Seal for Y-bearings
Lubrication Standard Lubrication
Special Treatment No Special Treatment

Data from Schaeffler (medias)

ECLASS number 23-05-16-03
ECLASS2 number 23-05-16-03
Medias description Take-up housing units PHEY, cast iron housing, radial insert ball bearing with grub screws in inner ring, P seals
