RALT25-XL INA

Housing unit

Stock
32 pcs in stock and ready for shipment
Brand INA
Article number RALT25-XL INA
Inside diameter 25mm
Outside diameter 95,2mm
Width 25,4mm
Product description

The RALT25-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: RALT25-XL INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 25
  2. Outer (D) MM 95,2
  3. Width (B) MM 25,4
  4. Inner (d) Inch 0.9843
  5. Outer (D) Inch 3.748
  6. Width (B) Inch 1
  7. Flange width (L) mm 71
  8. Height flange (H) mm 95,2
  9. Total height unit (U) mm 21,4

Suffix description

  1. XL X-Life

Technical details

  1. Availability 32 pcs
  2. Brand INA
  3. Item number RALT25-XL INA
  4. Also known as 0008439460000
    RALT25
  5. EAN 4012802786958
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 0.555

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 5900
  2. Radial Dynamic Load Rating Cr (N) 10700
  3. Basic static load rating, radial (C 0r) "5900.0000"
  4. Load carrying capacity (housing) (C 0r G) 3000
  5. Load carrying capacity (housing) (C g) 3000
  6. ECLASS number 23-05-16-02
  7. ECLASS2 number 23-05-16-02
  8. Medias description Flanged housing unit RALT..-XL
