RCJL70-XL-I INA

All dimensions

1. Inner (d) MM 70
2. Outer (D) MM 188
3. Width (B) MM 79,2
4. Inner (d) Inch 2.7559
5. Outer (D) Inch 7.4016
6. Width (B) Inch 3.1181
7. Flange width (L) mm 188
8. Total height unit (U) mm 79,2

Suffix description

1. XL X-Life
2. I Inch Size Grease Nipple R 1/8”

Technical details

1. Availability 4 pcs
2. Brand INA
3. Item number RCJL70-XL-I INA
4. Also known as 0008489800000
   NIP DIN71412-A R 1/8
   NIP DIN71412-B R 1/8
   NIP DIN71412-C R 1/8
   RCJL70-I

5. EAN 4012802800999
6. Category Housing and Bearing (assembly)

Weight and Dimensions

1. Weight (kg) 5.65

Product Properties

1. Seal 2F - Standard Seal for Y-bearings
2. Lubrication Standard Lubrication
3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 44000
2. Radial Dynamic Load Rating Cr (N) 66000
3. Basic static load rating, radial (C 0r) "44000.0000"
4. ECLASS number 23-05-16-02
5. ECLASS2 number 23-05-16-02
6. Medias description Housing units RCJL, four-bolt flanged housing units, cast iron, non-locating bearing, drive slot on inner ring, R seals
