RCJT35-XL-FA164 INA

All dimensions

1. Inner (d) MM 35
2. Inner (d) Inch 1.378
3. Flange width (L) mm 92
4. Height flange (H) mm 155
5. Total height unit (U) mm 53,5

Suffix description

1. XL X-Life
2. FA164 High Temperature Design Up To +250°C

Technical details

1. Availability 5 pcs
2. Brand INA
3. Item number RCJT35-XL-FA164 INA
4. Also known as 0009034420000
   RCJT35-FA164

5. EAN 4012802807233
6. Category Housing and Bearing (assembly)

Weight and Dimensions

1. Weight (kg) 1.25

Product Properties

1. Seal 2F - Standard Seal for Y-bearings
2. Lubrication Standard Lubrication
3. Special Treatment E - High Temp Design Up to +250°C

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 15300
2. Radial Dynamic Load Rating Cr (N) 27500
3. Basic static load rating, radial (C 0r) "15300.0000"
4. ECLASS number 23-05-16-02
5. ECLASS2 number 23-05-16-02
6. Medias description Housing units RCJT..-FA164, two-bolt flanged housing units, cast iron, eccentric locking collar, R seals, for temperatures up to +250°C

Downloads and links

1. X-life brochure X-life brochure
2. Link to manufacturer Link to manufacturer
