RFE30-XL INA

Housing unit

Stock
25 pcs in stock and ready for shipment
Brand INA
Article number RFE30-XL INA
Inside diameter 30mm
Outside diameter 127mm
Width 48,5mm
Product description

The RFE30-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: RFE30-XL INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 30
  2. Outer (D) MM 127
  3. Width (B) MM 48,5
  4. Inner (d) Inch 1.1811
  5. Outer (D) Inch 5
  6. Width (B) Inch 1.9094
  7. Height flange (H) mm 127
  8. Total height unit (U) mm 40,6

Suffix description

  1. XL X-Life

Technical details

  1. Availability 25 pcs
  2. Brand INA
  3. Item number RFE30-XL INA
  4. Also known as 0008276300000
    GE30KRRB + FE06
    RFE30
  5. EAN 4012802793727
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 1.025

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 11300
  2. Radial Dynamic Load Rating Cr (N) 20700
  3. Basic static load rating, radial (C 0r) "11300.0000"
  4. ECLASS number 23-05-16-02
  5. ECLASS2 number 23-05-16-02
  6. Medias description Housing units RFE, four-bolt flanged housing units, cast iron, centring spigot, eccentric locking collar, R seals
