RNA4909-XL INA

All dimensions

1. Inner (d) MM 52
2. Outer (D) MM 68
3. Width (B) MM 22
4. Inner (d) Inch 2.0472
5. Outer (D) Inch 2.6772
6. Width (B) Inch 0.8661
7. Under roller diameter (F w) mm 52
8. Width (b) mm 22

Suffix description

1. XL X-Life

Technical details

1. Availability 204 pcs
2. Brand INA
3. Item number RNA4909-XL INA
4. Also known as 0506511610000
   RNA4909

5. EAN 4012802436495
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.1865

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 73000
2. Radial Dynamic Load Rating Cr (N) 51000
3. Basic static load rating, radial (C 0r) "73000.0000"
4. Limiting speed (n G) 8600
5. Limiting speed for grease lubrication (n G Grease) 5200
6. Reference speed (n ϑr) 4900
7. ECLASS number 23-05-09-07
8. ECLASS2 number 23-05-09-07
9. Medias description Radial roller bearing RNA..-XL
