RPB30-XL INA

Housing unit

Stock
88 pcs in stock and ready for shipment
Brand INA
Article number RPB30-XL INA
Inside diameter 30mm
Outside diameter 117,5mm
Width 66,1mm
Product description

The RPB30-XL INA is a housing unit. The components of this bearing and housing assembly are matched to each other for reliable operation. This complete set is ready for use and easy to install. Housings simplify the installation of the bearing and shaft. Additionally, the bearing is supported and protected by the housing. Performing maintenance becomes easier while extending the bearing's lifespan.

Read more Show less
Help with this product

Downloads and links

Similar to: RPB30-XL INA

Loading similair products

Product specifications

All dimensions

  1. Inner (d) MM 30
  2. Outer (D) MM 117,5
  3. Width (B) MM 66,1
  4. Inner (d) Inch 1.1811
  5. Outer (D) Inch 4.626
  6. Width (B) Inch 2.6024
  7. Length total (L) mm 117,5
  8. Height (H 2) mm 66,1

Suffix description

  1. XL X-Life

Technical details

  1. Availability 88 pcs
  2. Brand INA
  3. Item number RPB30-XL INA
  4. Also known as 0008295790000
    RALE30NPPB + 62B/T
    RPB30
  5. EAN 4012802792362
  6. Category Housing and Bearing (assembly)

Weight and Dimensions

  1. Weight (kg) 0.45

Product Properties

  1. Seal 2F - Standard Seal for Y-bearings
  2. Lubrication Standard Lubrication
  3. Special Treatment No Special Treatment

Data from Schaeffler (medias)

  1. Radial Static Load Rating C0r (N) 8300
  2. Radial Dynamic Load Rating Cr (N) 14100
  3. Basic static load rating, radial (C 0r) "8300.0000"
  4. Load carrying capacity (housing) (C 0r G) 1400
  5. ECLASS number 23-05-16-01
  6. ECLASS2 number 23-05-16-01
  7. Medias description Plummer block housing units RPB, sheet steel housing, radial insert ball bearing with eccentric locking collar and rubber interliner, P seals

Downloads and links

  1. X-life brochure X-life brochure
  2. Link to manufacturer Link to manufacturer
