RPNA35/52-XL INA

All dimensions

1. Inner (d) MM 35
2. Outer (D) MM 52
3. Width (B) MM 20
4. Inner (d) Inch 1.378
5. Outer (D) Inch 2.0472
6. Width (B) Inch 0.7874
7. Under roller diameter (F w) mm 35

Suffix description

1. XL X-Life

Technical details

1. Availability 50 pcs
2. Brand INA
3. Item number RPNA35/52-XL INA
4. Also known as 0507797020000
   RPNA35/52

5. EAN 4012802735857
6. Category Needle Roller and Cage Assembly

Weight and Dimensions

1. Weight (kg) 0.142

Product Properties

1. Seal No Seal

Data from Schaeffler (medias)

1. Radial Static Load Rating C0r (N) 41500
2. Radial Dynamic Load Rating Cr (N) 27500
3. Basic static load rating, radial (C 0r) "41500.0000"
4. Limiting speed (n G) 12900
5. ECLASS number 23-05-09-07
6. ECLASS2 number 23-05-09-07
7. Medias description Aligning needle roller bearings RPNA, without inner ring
